銷售-上海-qlogic光纖卡-參數-舟若供

Qlogic光纖卡是qlogic公司光纖通道主機適配器HBA卡，Qlogic是嵌入式光纖通道交換機，堆疊式光纖通道交換機的領導廠商，該公司也是iscsi主機適配器，路由器的領先供應商，qlogic產品在世界上各個級別企業都有使用，IT行業中知名企業，比如思科，dell，netapp，EMC，HP都有采用qlogic方案

上海舟若電子有限公司主要經營原廠卡，有持續供貨能力，和國內多家客戶建立穩定的合作關系，歡迎洽談

qlogic的16GB光纖卡主要有qle2690和qle2692兩個，具體參數如下

Fibre Channel Specification
Throughput	3200Mbos full duplex line per port
Logins	Support for 2048 concurrent logins and 2048 active exchanges per port
Port	2 and 3
Port Virtualization	NPIV
Compliance	Fible Channel Physical Interface 5 (FC-PI5) Fible Channel Tape(FC-TAPE) Profile SCSI Fible Channel Protocol-2(FCP-2) SCSI-3 Fible Channel Protocol-2(FCP-2) Second Generation Fible Channel Generic Services (FC-GS-2) Third Generation Fible Generic Services(FC-GS-3)

Host Bus Interface Specification
Bus Interface	QLE2690/2692 PCI Express 3.0X8
Host Interrupts	INTx and MSI-X
Compliance	PCI-Express Base Specification, Rev.3.1 PCI-Express Card Electromechanical Specification Rve 3.0 PCI Bus Power Management Interface Specification Rev 1.2 PCI Hot Plug Specification Rev .1.1
Tools and Utilities
Management Tools and Device Utilities	QcomvergeConsole: a Unified management tool(GUI and CLI) that spans generations of Qlogic FC adapters
BOOT Support	BIOS Unified Extensible Firmware Interface(UEFI) Forth code(FCode)
APIs	SNIA HBA API V2 SMI-S
OS
End-End Provisioning and Management Features The following features require a supported Brocade switch running fabric OS Version 7.30a or later
Performance	Qos CS_CTL FEC Buffer-to-buffer credit recovery (BB-CR): automatic buffer credit loss detection and recovery
Diagnostics	Diagnostics Port LCB RDP
Deployment and Management	FA-WAN F-BLD FC ping FC traceroute VM-ID Fabric device management interface (FDMI) enhancements
Physical Specification
ports	QLE2690: sigle-port Gen 5 FC QLE2692：dual-port Gen 5 FC
Form Factor	Low Profile PCIe card(6.6inch*2.731inch) Custom form factors are also avaliable
Environment and Equipment Specifications
Temperature	Operating:0-55度 Storage:-20-70度
Humidity	Operating:10%-90% Storage:5%-95%
Maximum Cable Distances
Cable Distance	Rate Cable and Distance(m) OM1 OM2 OM3 OM4 4Gbps 70 150 380 400 8Gbps 21 50 150 190 16Gbps * 35 100 125
Agency Approvals-EMI and EMC (Class A)
US and Canada	FCC Rules,CFR Title 47, Part 15, subpart class A Industry Canada, ICES-003:Class A
Europe	EN55022 EN61000-3-2 EN55024 EN61000-3-3
Japan	VCCI: Class A
New Zealand and Australia	AS/NZS: Class A
Korea	KC-RRA Class A
Taiwan	BSMI CNS 13438
Ordering Information
QLE2690-SR-CK(Single port)	Ships in an individually packed box with a standard-height bracket installed Ships with SR optical transceivers installed
QLE2692-SR-CK(Dual port)	Ships in an individually packed box with a standard-height bracketinstalled Ships with SR optical transceivers installed
